Display

Thumb

Throttle

Disc Brake

Battery

Disc Brake

Seat Cushion Shock Absorber

Motor

Kickstand

Battery Lock

Sensor

3. Assembly and Set up

Installing The Front Wheel

1. Take out the screws and front fender. Install the front fender ﬁrst, and then install the front wheel.

gasket

screw nut

2. Remove the gasket on the front wheel shaft and the nuts on the left and right sides.

3. Remove the disc brake protective cover and insert the front axle into the hole at the center of the tire axle.

4. Align the tire center axis with the front fork, secure the front wheel, attach spacers and nuts on both sides, and use the installation

tool to tighten the nuts.
