SOLUTION TANK ASSEMBLY
ADMIRAL 98628 06/02/03
32
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 20041 2 CLAMP, 2.0" WORM GEAR
2 20042 1 CLAMP, 3/8 HOSE (D-SLOT)
3 27809 1 COVER, VAC MOTOR
4 27810 1 COVER, BELT
5 31081 1 ELBOW, 3/8 MPT X 3/8 TUBE, PLASTIC
6 35175 2 GASKET, TANK TO VAC COVER
7 35231 2 GASKET, VAC COVER (CLP FAMILY)
8 39526 1 HOSE,1/2 CLEAR X 12
9 39527 1 HOSE, 1.5 BLK VAC X 3.0
10 39528 REF HOSE ASM, 1.5 BLK VAC X 15.5
11 41348 1 HOUSING, VAC MOTOR
12 53789 1 VAC MOTOR ASM, CLP FAMILY
13 70525 6 SCR, #10 X 1.0 PPHST TYPE B
14 75259 1 TANK, ADM SOLUTION
15 85037 1 VENT, COOLING AIR SMALL
16 87018 11 WASHER, #10 X 9/16 OD
17 73864 1 STRAINER, 3/8 IN. NPT 60 MESH
18 87013 5 WASHER, 1/4 ID X 5/8 OD SS
19 70085 3 SCR, 1/4-20 X 1/2 PPHMS SS DL
20 20092 1 CLAMP, 3.5" WORM GEAR
21 35236 1 GASKET, TANK, L-F
22 35237 1 GASKET, TANK, L-R
23 35238 1 GASKET, TANK, RH
24 40027 1 HOSEBARB, 3/8MPTX1/2 90D DL
25 70360 2 SCR, 1/4-20 X.75 PPHMS PHIL
26 87025 2 WASHER, 1/4 LOCK EXT STAR SS
27 70114 5 SCR, #10 X 3/4 PPHST TYPE B
28 89183 1 WELDMENT, HANDLE PIVOT ADM8
29 57245 2 NUT, 1/4-20 HEX NYLOCK SS
30 02130 1 HOSE ASSY- FILL HOSE
31 20042 1 CLAMP, 3/8 HOSE (D-SLOT)
32 40023 1 HOSEBARB, 1/2MPT X 3/8 DL
33 75277 1 TANK ASM, SOLUTION ADM8 ITEMS INCLUDED
34 14258 - BRUSH SET, 5.7 2ST HP 116472 NOT SHOWN
*
*
