Windsor Chariot 3 iExtract 26 Duo User Manual

10186372820 Chariot 3 iExtract 26 Duo
Vacuum
* SEE SERIAL NUMBER PAGE
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86371470 1 HOSE ASM, 1.5 x 36.0
2 86371460 1 HOSE, 1.5" x 30", 4:1 STRETCH
3 86369990 1 MOUNT, DUAL VAC MOTOR
4 86323300 4 WASHER, 1/4" RUBBER
5 86312920 2 GASKET, VAC MOTOR
6 86276720 6 SCREW, 1/4-20 X 4.25 HHCS PLTD
7 86273810 4 SCREW, 1/4-20 X 1 HHCS SS
8 86005680 6 NUT, 1/4-20 HEX NYLOCK STL GR2 ZNPLT
9 86258480 2 VAC MOTOR, 36V 5.7 3ST TD
10 86201950 6 VAC SPACER 3 1/8
11 86010630 18 WASHER, 1/4 ID X 5/8 OD SS
12 86376030 1 HOSE ASM, 1.5 x 25.0, WIREBOUND
13 86002390 2 CLAMP, 1.75" WORM GEAR X .312
14 86264940 1 CABLE TIE, 11.38" UL/CSA
15 86375980 1 BRACKET, HOSE, VAC
16 86273780 2 SCREW, 1/4-20 X 3/4 HHCS SS NP
17 86326270 2 CLAMP, 1.5 DIA
18 86173340 2 WASHER, SPLIT LOCK, 1/4, SS
19 86271900 2 NUT, 10-24 HEXTHIN NYLOCK SS
20 86010650 2 WASHER, #10 X 9/16 OD
21 86378530 2 GASKET, VAC MOTOR COVER (3*)
22 86378690 2 RETAINING RING, VAC MOTOR (3*)

Windsor Chariot 3 iExtract 26 Duo Specifications

General

Brand	Windsor
Model	Chariot 3 iExtract 26 Duo
Category	Floor Machine
Language	English
