11586372820 Chariot 3 iExtract 26 Duo
Wiring 4
REF DESCRIPTION
A1 IDRIVE CONTROL
A2 CPU CONTROL
G1-G3 BATTERY 12V
M1 VACUUM MOTOR
M2 VACUUM MOTOR
M3 TRACTION MOTOR
M4 BRUSH MOTOR
M5 DECK ACTUATOR
M6 VACUUM ACTUATOR
S0 E STOP
S1 KEY SWITCH
S3 F/R SWITCH
S4 PLATFORM SWITCH
S5 WATER SWITCH
S6 HORN SWITCH
S7 OFF/AISLE TOOL SWITCH
Q1 MAIN ROTARY
K3 OFF/AISLE TOOL RELAY
Y1 BRAKE
Y2 WATER SOLENOID
V8 HOUR METER
V9 TRUECHARGE
H1 WATER LED
H2 HORN
F1 PCB 60A - U2
F2 IDRIVE 60A - U2
X12/X13/X14/X15 DEUTSCH CONNECTOR
X9/X10/X11 PACKARD CONNECTOR
