5786372820 Chariot 3 iExtract 26 Duo

Brush Deck Lift

* SEE SERIAL NUMBER PAGE

REF PART NO. QTY DESCRIPTION

SERIAL NO.

FROM

NOTES

1 86005630 2 NUT HEX NYL LOC-THIN SS 3/8-16

2 86373170 2 SPRING, EXT .859OD X 5.75 L

3 86372220 2 BRACKET, LIFT, LOWER, FRONT

4 86377910 4 BRACKET ASM, ACTUATOR (2*)

5 86370420 2 WASHER, .257IDX.625ODX.125 NYL BLK

6 86370400 1 BRKT, ACTUATOR, UPPER, OUTER

7 86370390 1 BRKT, ACTUATOR, LOWER WLDMNT

8 86370360 1 DECK LIFT WELDMENT

9 86364020 2 SHOULDER BOLT, 1/2 X 1.25 SS

10 86320880 1 ACT, 36VDC, 3.0" STK, 8.74 LNG

11 86278910 2 WASHER,3/8IDX7/8ODSS

12 86277130 2 SCREW, 5/16-18X1.00 CARRIAGE SS

13 86277030 2 SCREW, 5/16-18X1.25 CARRIAGE SS

14 86273740 1 SCREW, 1/4-20 x 1.5 HHCS SS

15 86270830 4 NUT, 5/16-18 HEX NYLOCK SS

16 86259410 4 WASHER, THRUST.51 ID X1ODX.063

17 86228990 2 BEARING,FLNGD,.314ID X.502OD

18 86228840 2 BUSHING, .314 X .502 X .5 FLG

19 86173340 1 WASHER, SPLIT LOCK, 1/4, SS

20 86010670 4 WASHER, 5/16 FLAT SS

21 86008650 1 PIN, COTTER RING 1/4 X .041 X .844

22 86006250 1 PIN, CLEVIS 1/4 X 1.75 STL ZNPLT

23 86264920 1 CABLE TIE, 7" UL/CSA
