8986372820 Chariot 3 iExtract 26 Duo
Solution System - Pump - Off-Aisle - For Models 10061780 & 10061790
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86391430 2 WASHER, .683 X 1.35 X .06 SS
2 86391420 1 BRACKET, MOUNT, PUMP
3 86391410 1 PLENUM, VACUUM
4 86371850 1 COUPLING, QD, 3/8 NPT
5 86276070 3 SCR, 5/16-18 X 3/4 CARRIAGE SS
6 86270990 4 NUT, 10-32 HEX NYLOCK SS
7 86368240 3 NUT, 5/16-18, FLGNYLOCK, SS
8 86264940 3 CABLE TIE, 11.38" UL/CSA
9 86257450 2 TERMINAL, 1060-16-0122
10 86250920 1 PUMP, 36VDC 100PSI
11 86247720 1 NIPPLE, 1/8 CLOSE
12 86246730 1 LOCK, W2P
13 86233760 1 CONNECTOR, DT04-2P
14 86200820 1 NIPPLE, 1/8
15 86197760 1 TEE, 1/4 STREET
16 86197420 1 ELBOW, 3/8NPT STREET
17 86197400 1 ELBOW, 1/8NPT STREET
18 86197390 1 ELBOW, 1/4NPT 45D STREET
19 86197300 1 BUSHING, 1/8 FPT X 1/4 MPT HEX
20 86197290 1 BUSHING, 3/8 MPT X 1/4 FPT HEX
21 - - OPEN
22 86010650 4 WASHER, #10 X 9/16 OD
23 86010630 2 WASHER 1/4 ID X 5/8 OD SS
24 86005810 2 NUT 1/4-20 HEX NYLOCK SS
25 86005590 1 NIPPLE 1/4 CLOSE
26 86005580 1 NIPPLE 1/4 FPT QD
To Next Page
