11
Operations
Technical Specifications - Basic
ITEM DIMENSION/CAPACITY
Nominal Power 1260 W
Rated Voltage 36 Volts DC
Rated Amperage 35 amps
Batteries 3 X12 Volt 130-195-215 AH @ 20 hr. rate
Battery Compartment Dimensions
23.5 in. x 15.5 in. x 16.5 in. tall
(600 mm x 400 mm x 420 mm)
Propelling Motor .5 HP (373 W)
Mass (GVW) 889 lbs (403 kg)
Weight Empty Without Batteries 340 lbs (154 kg)
Solution Control Metered flow with automatic shut-off in neutral and reverse
Spray Pump Pressure 100 psi (688 Kpa)
Solution Capacity 19.4 gal (74 Liter)
Spray Jets - Interim 2 Jets with total flow of 0.24 gal/min (0.9 Liter/min)
Spray Jets - Extraction 2 Jets with total flow of 1.05 gal/min (4.0 Liter/min)
Recovery Capacity 17.5 gal (66 Liter)
Vacuum Motors 1 x .75 Hp (560 W)
Scrub Brush Diameter 3.38” Inch (85.5 mm)
Scrub Brush Motor 1 x .5 Hp (375 W)
Scrub Brush Pressure Floating
Scrub Brush Speed 1084 rpm
Tires 9 in. (228mm) Solid Gray non-marking
Foundation Pressure 503 psi (3.5 Mpa)
Maximum (Transport) Speed Propel = 252 Ft/min (4.6 Km/hr)
Scrubbing Speed
Interim = 110 Ft/min (2.0 Km/hr)
Extract = 55 Ft/min (1.0 Km/hr
Frame Construction Powder coated steel
Minimum Aisle U-Turn Width 56 in. (1.4 Meter)
Maximum Rated Climb And Descent Angle 6 degrees
86400200 Operators Manual - Commodore Duo
