22
Operations
Filling Solution Tank
FOR SAFETY: Before leaving or servicing
machine; stop on level surface, turn off machine
and remove key.
1. Turn the machine power off.
2. Remove the front cover and the solution fill lid.
3. Fill the solution tank with clean water. (See the
Technical Specifications chart for exact capacity).
The water must not be hotter than 140° F (60°C) to
prevent damage to the tank.
4. Replace the solution fill lid and front cover.
Deluxe
1. Turn the machine power off.
2. Remove the front cover and the solution fill lid.
3. Fill the "A" tank with either encapsulating interim
carpet cleaning or pre-spray chemical.
4. Fill the "B" tank with extraction chemical or the
finishing rinse.
5. Turn machine power on.
6. Prime chemical system by holding the prime switch
to the "A" position for 30 seconds then holding the
prime switch to the "B" position for 30 seconds. If
using only one chemical tank, prime only that
system.
Flammable materials can cause an explosion or
fire. Do not use flammable materials in the tanks.
Les matières inflammables peuvent provoquer une
explosion ou un incendie. Ne pas utiliser de
matériaux inflammables dans les réservoirs.
Normal Scrubbing
Plan the scrubbing pattern in advance.
For efficient operation, the runs should be the longest
possible without turning, stopping, or raising or
lowering scrub deck. The longest track is around the
perimeter of the area to be cleaned and a collapsing
rectangle pattern is most efficient.
In order to achieve the best possible results, the area
which is to be cleaned, should be vacuumed before
scrubbing. Large debris, strings and wire must be
removed to prevent being caught in brushes.
If the machine is allowed to stand in neutral with the
scrub deck down for more than 2 seconds, the
solutions flow stops and brush motor stops. When
forward travel is resumed, the solution flow and the
scrub brush motor will continue. Overlap the brush
path and avoid transporting over previously cleaned
areas.
Recommended Scrubbing Path:
86400200 Operators Manual - Commodore Duo
