Windsor COMDU 1.008-612.0 User Manual

4186400210 Spare Parts List - Commodore Duo
Recovery Tank Handle - Deluxe
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86276490 3 SCR, 5/16-18 X 5/8 HHCS SS
2 86277640 4 SCR, 1/4-20 X 3/4 PTHMS SS
3 86290730 2 LATCH, FRONT COVER
4 86226740 4 SPACER, 3/8 X .265 X 1/4 NYL
5 86010800 2 WASHER, .21D X .500 BLK SS
6 86276290 2 SCR, #10 X 3/4 PPHST HI-LO BLK
7 86335690 1 ASSEMBLY, BRKT, FRONT, LEFT
8 86010630 6 WASHER, 1/4 ID X 5/8 OD SS
9 86271870 6 NUT, 1/4-20 HEX NYLOCK THIN SS
10 86294880 1 BRKT, ACC PORT COVER
11 86335620 1 COVER, ACCESSORY PORT
12 86222620 1 PIN, 5MM DIA X 85MM L
13 86008650 2 COTTER, 1/4" RING
14 86291800 1 ASSEMBLY, BRKT, FRONT, RIGHT
15 86010670 3 WASHER, 5/16 FLAT SS
16 86290850 1 SCR, M5 X 20 HHMS SS
17 86010650 3 WASHER, #10 X 9/16 OD
18 86275470 2 SCR, 10-32 X 5/8 PPHMS SS
19 86224770 1 SPRING, TORSION
20 86279170 1 WASHER, #10 X 1.0 FLAT
21 86295160 1 GASKET, ACCESSORY PORT COVER
22 86278910 1 WASHER, 3/8 ID X 7/8 OD SS
23 86200810 1 NIPPLE, 1/8 FPT QD FEM BRASS
24 86293920 1 BRKT, PRIMER SWITCH
25 86295720 1 LABEL, PRIMING
26 86270990 2 NUT, 10.32 HEX NYLOCK SS
27 86197520 1 HOSEBARB, 1/8MPT X 14 DL
28 86217270 1 COUPLER, ACC PORT VACUUM
29 86200820 1 NIPPLE, 1/8FPT QD MALE BRASS
30 86002400 2 CLAMP, 2.0" WORM GEAR X .312W
31 86240120 1 HOSE ASM, 1.5 BLK VAC X 5.0
32 86007210 1 SWITCH, DPDT 3-POSITION ROCKER
33 86005580 1 NIPPLE, 1/4 FPT QD
34 86197300 1 BUSHING, 1/8 FPT X 1/4 MPT HEX
35 86247720 1 NIPPLE, 1/8 CLOSE
36 86386620 1 WASHER, 3/8 X .630 X .039, DSP
