Windsor Compass 2 10070560 - Page 27

CONTROL PANEL
CMPS2 86305210 04/23/08
5-
2
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86233090 20016 3 CLAMP, 1/4 ID HOSE
2 86282280 39634 2 HOSE, 1/4 ID NYLOCBRAID X 23”
3 86232110 270699 2 CAMP CHEM FEED W/DIP TUBE
4 86258930 84187 1 VALVE, CHEMICAL METERING
5 86005700 57104 2 NUT, 10-32 W/STAR WASHER PLTD
6A 86001940 14635 1 BREAKER, 10A CIRUIT 120V
6B 86230110 14312 1 BREAKER, 7A CIRCUIT 230V
7A 86215670 140839 1 BREAKER, 8A VDE CIRCUIT 120V
7B 86230200 14831 1 BREAKER, 5A VDE CIRCUIT 230V
8 86302400 - 1 QD, NIPPLE, FOSTER 25 MPB
9 86197390 31021 1 ELBOW, 1/4 NPT 45D STREET
10 86279560 87178 3 WASHER, 5/8 ID X 1.70 D 0.05T
11 86276290 70626 4 SCR, #10 X 3/4 PPHST HI-LO BLK
12A 86297370 - 1 PANEL, SWITCH CONTROL 120V
12B 86302150 - 1 PANEL, 3 SWITCH CONTROL 230V
13 86002450 22015 1 COUPLER, 1/4 QD
14 86002010 14942 2 BOOT, 3/8 CIRCUIT BREAKER
15 86007200 72162 1 SWITCH, DPDT3-POSITION ROCKER
16 86238030 36235 2 GASKET, SWITCH CARLING
17 86007140 72130 1 SWITCH, SPST 2-POSITION ROCKER
18 86310280 - 1 SWITCH, DPST 2 POSITION ROCKER 230V ONLY
