Windsor Compass 2 10070560 - Wiring Diagram - 120 V

WIRING DIAGRAM - 120V
CMPS2 86305210 04/23/08
5-2
2
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86305020 - 1 HARNESS, MAIN
2 86305060 - 1 CORD SET, 14/3 X 31
3 86308000
-
1 WIRE, 6” BLK/14 76050 X 76029
4 88305070 - 2 WIRE, 2”, BLK/14 76050 X 76029
5 86268570 88401 2 WIRE, 3”, BLK/14 76029X 76029
6 86307990 - 1 WIRE, 10”, GRN/14 76010 X 76010
7 86234200 23215 1 CORD SET, 14/3X50’ GFCI YLW
