Windsor Compass 2 10070560 - Page 33

SOLUTION - INJECTOR ASSEMBLY
CMPS2 86305210 02/19/09
5-8
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86302410 - 3 QD, COUPLER, FOSTER 25FS
2 86302570 - 1 HOSE, PULSE, 3/8F X 3/8F X 45”
3 86197760 78308 2 TEE, 1/4 STREET
4 86247680 56015 2 NIPPLE, 1/4 HEX
5 86303760 - 1 VALVE, SOLENOID, 1/4F 700PSI
6A 86303850 - 1 COIL, 115V, SOLENOID
6B 86308530 - 1 COIL, 230V, SOLENOID, CMPS2
7 86197300 14079 1 BUSHING, 1/8 FPT X 1/4 MPT HEX
8 86303770 - 1 INJECTOR KIT, DEMA, 200-3C
9 86305750 - 1 NIPPLE, 1/4 X 1/8 REDUCING HEX
10 86303750 - 1 HOSE, ASM, 1/4F X 1/4M, 7”
11 86197370 31017 1 ELBOW, 1/4FPT X 1/4FPT
12 86006630 70171 2 SCR, 10-24 X 1/2 HHMS SS
13 86010650 87018 2 WASHER, #10 X 9/16 OD
14 86006490 70013 2 SCR, 8-32 X 3/4 PPHMS
15 86305200 - 1 TERMINAL BLOCK, 115/230V
16 86273980 70066 2 SCR, 10-32 X 3/4 PPHMS
17 86302400 - 1 QD, NIPPLE, FOSTER 25MPB
18 86005700 57104
4
NUT, 10-32 W/STAR WASHER PLTD
19 86233090 20016 1 CLAMP, 1/4 ID HOSE
20 86295830 - 1 HOSE, 1/4ID NYLOBRAID X 41”
21 86264940 27051 6 CABLE TIE, 11.38” UL/CSA
22 86197290 14076 1 BUSHING, 3/8 MPT X 1/4 FPT HEX
23 86302790 - 1
HOSE, PULSE, 1/4 MPLT X 1/4
MPLT X 30”
24 86188130 11-800151 1 NIPPLE, 3/8M X 1/4M
25 86264940 27051 1 CABLE TIE, 11.38” UL/CSA
26 86308560 - 1 ASM, FILTER MAIN 230V ONLY
