Windsor Compass 2 10070560 - Page 35

SOLUTION-PUMP
CMPS2 86305210 04/23/08
5-1
0
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86302790 - 1
HOSE, PULSE, 1/4MSWL X 3/8NPT X
30”
2 86197610 40034 1 HOSEBARB, 3/8MPTX3/8 90D DL
3 86233090 20016 1 CLAMP, 1/4 ID HOSE
4 86302780 - 1 HOSE, BRAIDED, 3/8ID X 16” L
5A 86302820 - 1 PUMP, PUMPTEC, 700PSI
5B 86308100 - 1 PUMP, PUMPTEC, 700PSI, 230V
6 86197540 40013 1 HOSEBARB, 3/8MPT X 1/2 DL
7 86190520 11-800224 4 PLUG, 3/8 SOCHD BR
8 86302770 - 1 HOSE, BRAIDED, 1/2 ID X 14” L
9 86197940 40027 2 HOSEBARB, 3/8MPTX1/2 90D DL
10 86305460 - 1 STRAINER, 3/8 FPT 80 MESH
11 86302760 - 1 HOSE, BRAIDED, 1/2 ID X 4-3/4” L
12 86233150 20042 3 CLAMP, 3/8 HOSE (D-SLOT)
13 86302720 - 1 MOTOR, 700PSI, 115/230 VOLT
14 86302730 - 1 UNLOADER, 800PSI, PUMPTEC
15 86264940 27051 5 CABLE TIE, 11.38” UL/CSA
16 86197380 31018 1 ELBOW, 3/8FPT X 1/4FPT
17 86005590 56014 1 NIPPLE, 1/4 CLOSE
18 86197370 31017 1 ELBOW, 1/4FPT X 1/4FPT
19 86302400 - 1 QD, NIPPLE, FOSTER 25MPB
20 86302410 - 2 QD, COUPLER, FOSTER 25FS
