Windsor Compass 2 10070560 - Page 39

RECOVERY TANK
CMPS2 86305210 01/14/08
5-1
4
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86277040 70781 11 SCR, 5/16-18 X 1/2 HHCS SS NP
2 86010670 87029 11 WASHER, 5/16 FLAT SS
3 86070510 140659 1 BRKT, TANK MOUNT
4 86002620 260-64A 1 ACCESS COVER CLEAR 6” W/RIM
5 86275800 70546 6 SCR, 8 X 3/4 PFHT/S BLK ZINC
6 86004000 35255 1 GASKET, TANK LID
7 86033250 66402 1 PIPE ASM, VACUUM STACK
8 86199840 090-12A 1
FLOAT SCREEN CAGE ASSY
(SLIP)
9 86233110 20018 1 CLAMP, 1.0” WORM GEAR
10 86300900 - 1 TANK, REC DK GRY 2
11 86271850 57287 1 NUT, 1/2 NPT PLASTIC
12 86296560 - 1 BRACKET, UTILITY MOUNT, 2.0
13 86240790 82358 1 HOSEBARB, 1/2 MPT X 3/4 90D
14 86302360 - 1 DRAIN HOSE
15 86177050 03-000176 1 CLAMP, HOSE #20
16 86302590 - 1 HOSE, CLEAR, 3/4ID X 34”
