LOWER HANDLE GROUP
MB2000I 980071 11/15/02
5-6
REF PART NO. QTY DESCRIPTION
SERIAL
NO.
NOTES:
1 70738 1 SCR, M5 X .8MM X 10 MM PPHMS BLK
2 20005 1 CLAMP, 5/16 NYLON
3 67468 2 RING, 10MM EXTERNAL SNAP
4 66340 1 PIN, DOWEL 10MM DIA X 124 MM LG
5 140421 1 BRACKET, HANDLE LINK
6 67469 2 RING, 13MM EXTERNAL SNAP
7 87234 2 WASHER, 14MM ID X 36MM OD X 2MM
8 87203 8 WASHER, 14MM ID X 35 MM OD
9 730052 1 SPACER, LINKAGE
10 500542 1 LABEL, HANDLE RELEASE
11 51358 1 LATCH, HANDLE
12 89206 2 WHEEL. 5D X 1.25 X 13MM ID GRY
13 730055 1 SPRING, 180 DEGREE TORSION
14 140420 1 BLOCK, SPRING COMPRESSION
15 730054 1 SPRING, COMP 1.140 OD X 8.40 L X .150 W
16 57119 1 NUT, 3/8-16 HEX NYLOCK
17 87171 2 WASHER, 3/8 FLAT
18 70069 1 SCR, 3/8-16 X 3 HHCS GR5
19 140419 2 BRACKET, HANDLE MOUNT
20 70262 1 SCR, M8 X 20 HHMS PLTD
21 87054 2 WASHER, M8 FLAT DIN125A PLT
22 05157 1 AXLE, REAR
23 70733 4 SCR, M6 X 30 SHCS PLTD
24 730053 1 STRIKER, LATCH
