Windsor VS 14 User Manual

Pos.
Code
1 1910
1918
2 1037 EH
3 1596 hg
4 1794
5 1949 bl
6 1420 hg
7 1548 hg
8 1038 bl
9 1792 hg
10 0517
1280
11 1069 UL
12 1477
1281
13 0818
14 1283 UL
15 1030
16 1026 UL
17 1040
18 1041
19 1027
20 1025
21 1073
22 1044
23 1534 hg
24 1139 bl
25 1059
26
1061
27
1057 BL
28 1461 bl
29 1462 BL
30 1517 hg
31 1516 hg
32 1797 WI
33 1521 hg
34 1798 dg
35 1896
36
1553
37 0819 dg
38 1887 UL
39 0511/1
40 1821 UL
41 1411
42
1047
43
1545
44 1265 UL
45 1524
46
0101
47 0102
48 0103
49
0111
50 0140
51 1034 hg
Description
Cable 14)
Cable
18)
Handle grip
Handle cover
Handle
Dust bag housing
Grommet
Switch button
Connecting tube
Retaining ring
Switch
Switch cover
Switch holder
Prited circuit board
PC-board cover
Antistatic wire
Internal cable
Cable clamp
Switch housing cover
Dust bag lever
Return spring
Leaf spring
Connecting rod
Clamp
Motor filter
Exhaust filter
Back cover
Back cover seal
Gasket
Latch with spring and pin
Cable hook
Cable hook,
Hand nozzle
Hose
Motor housing
Housing cover r. h.
Filter retaining button
Sound insulation
Locking rod
Locking catch
Vac motor 120V / 1000W/
lamb
Carbon brush set
vac mot.
Motor cover
Motor support
motor seal
Contact holder 3-wire
Terminal block 3-wire
Terminal block cover
Screw C
x DIN 7981
Screw F
x 13 DIN 7981
Screw C
x 16 DIN 7981
Screw AM5 x 30
DIN 7985
Washer
DIN 125
Retaining ring
