WAVE Instructions page 9
Trouble Shooting Chart
Condition Corrective Action
No Power To Machine:
Dead electrical circuit breaker in fuse box Check building circuit breaker.
Faulty power cord Test power cord for continuity I Replace if necessary.
Power switch failure Test switch for continuity. Replace if necessary
Faulty circuit breaker Test circuit breakers for continuity/ Replace if necessary.
Intemal wiring problem With the machine unplugged, check for, and correct, any loose wire
connections inside the machine at the switches and terminal block.
Electrical Shock:
Equipment not grounding Follow grounding instructions exactly.
Receptacle not grounded Have an electrician inspect the building’s wiring.
Internal electrical problem Ensure that the machine’s wiring matches the appropriate wiring diagram.
Check for and correct any loose wire conneetions~ Replace any wires or
components which are short circuiting.
Vacuum Motor Soeed Varies or Doesn’t Run:
Circuit breaker tripped Reset vac motor circuit breaker (13 amp).
Faulty vac circuit breaker Check for continuity I Replace as necessary.
Intemal wiring problem With the machine unplugged, check for, and correct, any loose wire
connections inside the machine at the switches and terminal block.
Power switch failure Test switch for continuity I Replace if necessary.
Wom motor brushes Replace if less than 1I4”.
Brush Motors do not run:
Circuit breaker tripped Reset brush motor circuit breaker (2 amp).
Faulty brush circuit breaker Check for continuity / Replace as necessary.
Internal wiring problem With the machine unplugged, check for, and correct; any loose wire
connections inside the machine at the switches and terminal block.
Fautly brush switch Remove leads and check switch for continuity. Replace.
Wom motor brushes Replace if less than 3/8”.
Mechanical problems Higher amp draws may indicate a mechanical problem. Find parts which are not moving freely
and repair or replace.
Faulty brush motor If the belt, circuit breaker, and switch have been tested and found in good
working order, the brush motor may need to be replaced.
Loss Of Vacuum:
Bag full Replace
Flapper in correct position FLOOR TOOL
Damaged lid gasket Replace
Accessory tool clogged Clean out tool, ensure free airflow.
Vac hose damaged Replace
Debris Chute Clogged Remove chute access PN 05125 and clean chute out.
