Functions
of
the display:
Green light (a)
:
Brush lowers
Green light (b)
:
Brush raises
Red light (c)
:
Continuous
-
change brush
roller
Red light (c)
:
Flashing and motor off-
Brush jammed
-
clear
Red light (c)
:
Flashing and motor on
(when machine is upright
position)
-
Take care: Brush
in contact with carpet.
(d)
:
Continuous
-
change paper
bag or clear blockage
(d)
:
Flashing
-
motor switched
off due to
full
paper bag or
blockage.
Red light
Red light
I
On hard floors the adjustment wheel (41),
moves upwards into the machine
so
that the
brush becomes flush with the floor.
Therefore, the WINDSOR
"
SENSOR
"
can
also be used to vacuum hard floors.
On carpeted floors the adjustment wheel (41)
moves downwards out of the machine
so
that
the brush rises. The adjustment wheel (41)
rises and lowers to adjust the brush to the
optimal setting. This combines effective, gentle
brushing with a smooth easy action.
When the machine is switched on in the up
-
right position the brush automatically rises
from the carpet. To release the machine from
the upright position, press down the foot pedal
(18). The brush will automatically lower. The
handle can be lowered to an intermediate stop
position in order to lift up the brush head.
To
lower the handle to a horizontal position, the
foot pedal must be pressed a second time. The
stop position can be closed off by a slider on
the swivel neck (1
9)
so
that the handle will go
from vertical to horizontal in one movement.
To vacuum in corners etc.,
take hold of the telescopic handle grip,
lift.it
away from the machine and stretch out the
hose. After use insert the telescopic
attachment tube into the back of the
machine. Raise the handle of the machine
and the hose will automatically retract. To
use the hose without the tube as shown in
the right hand picture, the hose will pull out
of
the tube while the tube is fitted to the
machine. Alternatively, press the release
catch
(27)
on picture
2.
To vacuum under beds etc., the
WINDSOR
"
SENSOR
"
can be fitted with an
additional straight tube and the floor nozzle.
The machine will then perform as a cylinder
vacuum.
Never run over the cable with the brush/
suction head.
Always carry the machine over steps and
sills.
