Antenna Specifications| frequency range | 10.95 - 12.75 GHz |
|---|---|
| gain at 11.2 GHz | 33.22 dBi |
| gain at 12.1 GHz | 33.89 dBi |
| gain at 12.6 GHz | 34.23 dBi |
| aperture efficiency | 73% |
| cross polarization on axis | -21 dB |
| beamwidth at -3 dB | 3.5[o] |
| beamwidth at -10 dB | 7.0[o] |
Weight and Dimensions| height when raised | 30" |
|---|---|
| height in the travel position | 8" |
| operating radius | 17" |
| roof space required | 26" |
| weight | 12 lbs |
| antenna height | 20.9" |
| antenna width | 19.2" |
| ship weight | 20.6 lbs |
