ALIGN WITH
BASEPLATE
AREA MARKED
“FRONT”
POINT TO FRONT
OF VEHICLE
Roof Template
1/8” DRILL BIT
8 HOLES. DO NOT
DRILL THROUGH CEILING.
1-3/4” DIA.
DRILL COMPLETELY
THROUGH CEILING
