USER GUIDE WINEARM15 Page 10
2.2.4. Air flow ventilation
Separate the air flows. The free cross-section of each grid is 200 cm². Separation A is not provided.
Be sure to seal this separation.
Additional sound insulation is possible. It is particularly useful for suction on all walls
A
