Chapter 1 Product Introduction
2
NF4K8AB Series User Manual
Main Features
Size:
ATX form factor of 12” x 9.6”
Microprocessor:
Supports AMD socket 754 Sempron
TM
, Athlon
TM
64 processors
Supports HyperTransport technology
Chipset:
NVIDIA chipset: nForce4
System Memory
Three 184-pin DDR DIMM slots
Supports PC3200/2700/2100 memory
Supports 128/256/512/1024Mb technology up to 3GB
USB 2.0 Port
Supports hot-plug
Ten USB 2.0 ports (four rear panel ports, three onboard USB headers
providing six extra ports)
Supports wake-up from S1 and S3 mode
Supports USB 2.0 protocol up to 480Mbps transmission rate
Onboard Serial ATA
150MBps transfer rate
Supports four S-ATA devices
NVIDIA RAID Technology
supports RAID 0, RAID 1, RAID 0+1 and JBOD
Cross-controller RAID uniquely supports both SATA and PATA disk devices within
a single array
Onboard LAN (-L/-K) (optional)
Supports10/100/1000 (-K optional) Mbps Ethernet
LAN interface built-in on board
Note: The shielded LAN cables are recommended.
