Winnebago INTENT User Manual

1-5
SECTION 1 -
INTRODUCTION
SPECIFICATIONS AND CAPACITIES
28Y 29L 30R 31P
Ford
®
F53
18,000 lb.
Chassis with
19.5" Tires
Ford
®
F53
18,000 lb.
Chassis with
19.5" Tires
Ford
®
F53
16,000 lb.
Chassis with
19.5" Tires
Ford
®
F53
18,000 lb.
Chassis with
19.5" Tires
Feature Number
16H 16H 16N 16H
Length
28' 9" 29' 10" 30' 10" 31' 10"
Exterior Height
1
12' 12' 12' 12'
Exterior Width
2
8' 5" 8' 5" 8' 5" 8' 5"
Exterior Storage
3
80 cu. ft. 88 cu. ft. 114 cu. ft. 100 cu. ft.
Awning Length
21' 22' 22' 24'
Interior Height
7' 7' 7' 7'
Interior Width
8' 0.25" 8' 0.25" 8' 0.25" 8' 0.25"
Freshwater Tank Capacity
4
48 gal. 48 gal. 51 gal. 48 gal.
Water Heater Capacity
6 gal. 6 gal. 6 gal. 6 gal.
Holding Tank Capacity - Black
4
31 gal. 37 gal. 36 gal 35 gal
Holding Tank Capacity - Gray
4
45 gal. 43 gal. 42 gal. 40 gal.
Propane Capacity
5 & 7
11.2 gal 11.2 gal 11.2 gal 11.2 gal
Wheelbase
178" 190" 190" 208"
GVWR
18,000 lbs. 18,000 lbs. 16,000 lbs. 18,000 lbs.
GAWR - Front
7,000 lbs. 7,000 lbs. 6,500 lbs. 7,000 lbs.
GAWR - Rear
12,000 lbs. 12,000 lbs. 11,000 lbs. 12,000 lbs.
GCWR
6
23,000 lbs. 23,000 lbs. 23,000 lbs. 23,000 lbs.
Fuel Capacity 80 gal. 80 gal. 80 gal. 80 gal.
Notes:
7
40 .lbs installed, 60 .lbs max capacity with customer add on 20lb. cylinder.
4
Capacities are based on measurements prior to tank installation. Slight capacity variations can result upon installation.
6
Actual towing capacity is dependent on your particular loading and towing circumstances which includes the GVWR, GAWR,
and GCWR as well as adequate trailer brakes. Refer to the chassis operator's manual of your motor home for further towing
information.
All information is based upon the most recent data available. Visit the Winnebago Industries, Inc. web page –
www.winnebagoind.com – for the most current product information.
1
The height of each model is measured to the top of the tallest standard feature and is based on the curb weight of a typically
equipped unit. The actual height of your vehicle may vary by several inches depending on chassis or equipment variations.
Contact your dealer for further information.
2
Floorplans feature a wide-body design - over 96". You should be aware that some states restrict access on some or all state
roads to 96" in body width. You should confirm the road usage laws in the states of interest to you.
3
The load capacity of your motor home is designated by weight, not by volume, so you cannot necessarily use all available
space when loading your motor home.
5
Capacities shown are the tank manufacturer's listed water capacity (W.C.). Actual filled propane capacity is 80% of listing due
to overfilling prevention device on tank.

Winnebago INTENT Specifications

General

Engine	7.3L V8
Fuel Type	Gasoline
Category	Class C
Manufacturer	Winnebago
Model	Intent
Horsepower	350 hp
Torque	468 lb-ft
Fuel Capacity	55 gal.
Chassis	Ford
