SECTION 7 -
PLUMBING
7-16
WATER SYSTEM DRAIN VALVE LOCATIONS
System Drain Valve Locations
Waterlines
• Two (2) waterline drain valves located in the passenger
side compartment behind rear axle.
Also, place the tip of your finger inside the city water
connection and gently press the backflow valve (small
“button” in center of connector) to drain any water left in
the city waterline.
Water Tank
• One (1) valve located in the passenger side compartment
behind rear axle.
Water Heater
• Drain plug on outside of the motorhome behind service
door. Use socket to remove drain plug.
Water Heater Bypass
Valve
• Models 26M and 30R: One (1) valve located beneath
galley refrigerator. Remove furnace air intake grill to
access.
• Models 29L, and 31P: One (1) valve inside cabinet
beneath galley sink. Remove lower galley drawer to
access.
• Model V28Y: One (1) valve located in the driver side #2
compartment door, remove 2 panels to access.
Winterization (Antifreeze)
Valve
• Valve with clear vinyl siphon tube is located in the
passenger side compartment behind rear axle.
