SECTION 9 -
FURNITURE AND SOFTGOODS
9-2
4. Push table straight down. Lower dinette seat
cushions.
5. Rotate lock rod up to secure table in the
lowered position.
6. Arrange dinette cushions to cover bed area.
NOTE: Additional bolsters may be included with
your dinette to cover bed area.
Reverse steps to convert back into dinette
seating.
Once the table is up, engage the lock rod by
pushing the lock rod up.
Hi-Lo Table Operation
1. Depress metal buttons on both sides of the
table, just under the edges
2. Detailed view of Button
3. After pushing in buttons, lift up on table.
Failure to engage the lock rod when the
table is raised may result in injury.
