SECTION 3
GETTING TO KNOW YOUR MOTOR HOME
3 - GETTING TO KNOW YOUR MOTOR HOME
If your model has a dinette seat located
directly behind the driver or passenger front seat,
the dinette seat back is hinged and can be folded
down to allow full use of the front seat reclining
feature. Simply remove the seat back cushion and
unlatch the bolt latches on both sides of the
dinette seat as shown, then fold downward.
SEAT BELTS
Seats intended for occupancy while the vehi-
cle is in motion are equipped with seat belts for
the protection of the driver and passengers.
Lap Belts
The lap belts must be worn as low as possible
and fit snugly across the hip area. Always sit
erect and well back into the seat. To gain full pro-
tection of the safety belt, never let more than one
person use the same safety belt at any one time,
and do not let the safety belts become damaged
by pinching them in the doors or in the seat mech-
anism. After any serious accident, any seat belts
which were in use at the time should be replaced.
Adjustment: To lengthen belt, turn tongue at a
right angle to belt and pull to desired length.
To shorten, pull loose end of belt.
To Fasten: Be sure belt is not twisted. Grasp
each part of the belt assembly and push
tongue into buckle. Adjust to a snug fit by
pulling the loose end away from the tongue.
To Release: Press button in center of buckle and
slide tongue out of buckle.
Do not adjust driver’s seat while vehi-
cle is in motion.
After adjusting seat, always use body
pressure to make sure slide and
swivel locking mechanism have
engaged.
Dinette Seatback Latch
(Remove cushion and unbolt to fold down
Dinette seat folds down to allow front
seat reclining.
