SECTION 12
FURNITURE & SOFTGOODS
12-2
2. Remove the table from the wall support
bracket by lifting the end of the table. Then
lower the table to rest on the cleats attached
to each dinette bench.
3. Arrange dinette cushions to cover bed area.
Bed to Dinette:
1. Replace the table onto the wall support and
lower the table leg.
2. Make sure that the table leg is secured into
the floor support bracket and the leg brace is
locked.
U-Shaped Dinette/Bed Conversion -
Optional (Model 327L only)
The round dinette can be converted into addi-
tional sleeping space when needed by lowering
the table and moving a cushion into place as
shown below.
1. Get a partner to help you lift the table
upward off the support tubes and set the table
edgewise onto the floor to remove the table
leg tubes.
2. Pull table tubes from the floor or table sock-
ets depending on which socket into which
they have remained fitted.
3. Store table leg tubes beneath dinette seat.
4. Be sure leaf extension is lowered.
5. Place the table, ‘flat’ side outward, in the
‘notch’ - lowering it onto the table support
columns on the dinette seat face.
To Next Page
