5.4 To adjust the running paƩern
1. This robŽƟc cleaner comes with 2 adjustable wheels. By modifying the combinaƟŽn of these 2
adjustable wheels, it will change the running paƩern of the cleaner.
2. To adjust the wheel, open the lock buckles and remove the top cover. Locate the 2 adjustable
wheels. Detach the wheel by pushing the wheel stem catch. Select the correct combinaƟon and
insert the wheel unƟů the catch clicks.
3. CombinaƟons:
A – C for most types of pool (factory seƫng)
B – C Smaller rebounding angle than A – C
C – C Minimum maneuvering (For rectangular or longer pool)
A – B For round pools
Adjustable Wheels
Wheel Stem Catch
Sleeve
