WINTACT WT8812 - 1. Before Use; Check Up

-01-
1.Before use
Thanks for your purchasing our product, please check the following
components after you unpacking the box. If there is any missing or
wrong page manual,please contact the local dealer.
Check up
Compound Gas Monitor（Contain Alligator clips） 1PCS
Charger 1 PCS
Transparent trachea 1PCS
Cover (with screws) 1PCS
Manual 1 PCS
Data line 1PCS
When you are ready to use this product, please make sure to read this
manual first, and follow the relevant operations in usage so that you can
fully understand the company's products and services while also avoiding
unnecessary man-made damage or other accidents.
Contents
1.Before use
2.Operation manual
Check up-------------------------------------------------- (01)
Introduction-----------------------------------------------
(02)
LCD Displays-------------- ----------------(03)
Name of parts---------------------------------------------(04)
Functions--------------------------------------------------(05)
Specifications-------------------------------------------- (06)
---------------
Main interface (07)
Measurement Interface --------------------------------(12)
Record Checking Interface-----------------------------(13)
--------------------------------------------
3.Others
Charging function description------------------------- (13)
Warnings and Precautions----------------------------- (14)
