3 Parts installation
3.1 Suction cups installation
1
Remove four nuts on the suction cups. Insert four screws through the plate, then
tighten the nuts.
Note: Please clean the suction cups and your desk before installation.
3.2 Cams installation
Please refer to
EX1-J2-2 User Manual
.
3.3 Resistance model
Please refer to
EX1-J2-2 User Manual.
