4.2 Mounting installation
1 Remove the 4 screws on the bottom, then remove the plate;
2 Put the BASE on the mount, then install screws and spacers (prepared by yourself)from
the bottom to fix it on the mounting. .
Note: The mount, screws and spacers should be prepared yourselves.( Additional attention
to the length of screws:5 mm M4 screws)
