Pushing the knob from the Status menu, it is possible to enter on the configuration setting of each
input port:
ports 1÷4 (diversity configuration 4->2) or ports 1÷8 (no diversity configuration, 8->1 or 8->2) ❷
For each port it is possible to:
 enable RF input (only in diversity configuration 4->2)
o both A&B ports (AB)
o only A (A-)
o only B (-B)
NOTE: push the square button to disable RF input of both the ports (A & B): the button
becomes unlighted.
 enable power supply DC (12V/250mA) to antenna booster
Configuration 4->2
Configuration 8->1 or 8->4
AB
DC enabled on both ports A&B
N
DC enabled
A-
DC enabled only on port A
-
no DC enabled
-B
DC enabled only on port B
--
no DC enabled
 enable power supply DC with extra current (12V/800mA) ex. BAW
ONLY FOR PORT1 and PORT5
Configuration 4->2
Port 1a and Port 1b
Configuration 8->1 or 8->4
Port 1 and Port 5
HH
DC with extra current enabled on
ports 1a and 1b
H
DC with extra current enabled on port
1 or port 5
H-
DC with extra current enabled on
port 1a
-H
DC with extra current enabled on
port 1b
HB
DC with extra current enabled on
port 1a and standard DC on port 1b
AH
DC with extra current enabled on
port 1b and standard DC on port 1a
According to the DC antenna booster setting, the square button in the front panel can be
o lighted fixed blue (AB) or (N)
o lighted flashing blue for 5 sec, then fixed blue (A- or –B)
o lighted fixed green (--)
 change the gain/attenuation on antenna A or B (from 7 to 24.5 dB, step 0.5)
