RF Matrix
MAT244 is a programmable RF combiner. By entering into RF Matrix menu you can configure the
software picking one of the three following options:
• Combiner 8:1 with 7dB gain max
• Combiner 8:4 with 0dB gain max
• Diversity Combiner 4:2 with 7dB gain max
Antennas Diagnosis
This submenu allows you to check the value levels of
voltage (V) and current (I) of the 8 antennas of MAT244.
Name
The NAME submenu let you change the name of your
matrix that will be visible on the status menu and the
name of the Areas that will be visible on the monitoring
by Wisycom Manager:
Display brightness and display timeout
In these two menus you can increase or decrease display brightness or modify the time before the
display turns darker.
Info
Here you can check all the basic info about your MAT244 such as IP address, serial number,
Firmware, alarms etc.
