DISPLAY MENU
Using up/down selector all menus can be accessed in sequence.
* Depending on the Power Profile
MENU
STATUS
PRESET
Current
Load
FACTORY/USER/PRESET1/2/3/4/5/
6/7/8
Save
USER
TUNING
CH 00-59
GR 00-39
Freq
depend on the bandwidth of the Tx
AUDIO
AF In Gain
AF Level
-40÷40 dB (1dB step)
-54÷+26dBu (1dB step)
Phase 0/180
HP Filter flat/60/80/120/170/250/400Hz
Noise R. ENR-Wisy/ENC-Wisy
MOD Wide/Narrow
LP Filter 12/15/20kHz
RF/Battery
RF Power
10/L20/50/100mW*
Battery Alkaline/NiMH/Lithium
LED
Led Light 0÷16
Led Mode
None/ModPeak/PTT
MIC
PTT
Disable/Normal/Muting/No Data
NAME Tx Name
INFO FW/HW/SN/BW/BL/OPT
IRDA
LOCK
To Next Page
