WisyCom MTP40S - Device Dimensions and Variants; Physical Dimensions; Country Variants and Options

MTP40S User Manual
19
VARIANTS:
▪ AUDIO CONNECTOR
LM 3 PIN LEMO CONNECTOR
DP 2 PIN DPA MICRODOT CONNECTOR
▪ COLOR
PV
body color titanium gray (ceramic coating)
BL body color black (powder coating)
▪ FREQUENCY RANGE
B1 470-640 MHz
B2 566-798 MHz
B3 510-698 MHz
POWER PROFILE & COUNTRY
FREQUENCY RANGE:
EU max power 50mW (Europe)
0W1 / EUX max power 100mW (Europe)
US max power 50mW (USA)
USX max power 100mW (USA & Canada)
JP max power 10mW (Japan)
NZ max power 100mW (New Zealand)
OPTIONS:
ADT hole on battery housing for ADT40
For commercial code, see Variants area of Wisycom Products on website
MTP40S
Note: unit is mm
