MTP40S User Manual
5
DISPLAY MENU
Setup menu are accessed in sequence:
MENU
STATUS
PRESET
Current
Load
FACTORY/USER/PRESET1/2/3/4/5/6/7/8
Save
USER
TUNING
CH 00-59
GR 00-39
Freq
1: 470.000÷640.000
2: 566.000÷798.000
3: 510.000÷698.000
AUDIO
AF In Gain
AF Level
-60 ÷ +40 dB (1dB step)
-54 ÷ +46 dBu (1dBu step)
Phase 0/180
HPass Filter Flat/60/80/120/170/250/400Hz
Noise R.
ENR-Wisy/ENC-Wisy
Limiter On/Off
MIC
Mode
2 wires/2wires+bias/3 wires/
2wire&pha/2w+bias&pha
PTT
Disable/Normal/Muting/No Data
Name
RF/Battery
RF Power
10/50/100mW *
Battery
Alkaline/NiMH/Lithium
LED
Led Light 0÷16
Led Mode
None/ModPeak/PTT
Info
IRDA
Lock
Preset parameters
* Depending on the Power Profile
