8.2 Setting pressure reducer
Setting pressure reducer without laptop
 Start service program  service routine  setting
pressure reducer  start.
 Remove screw-cap on water tank filler.
 Screw auxiliary nipple to accept plug-in connector into
the water tank filler
 Mount auxiliary tool on filler.
 Press field
Start
Supply valve opens
 Read pressure on pressure gauge.
 Set pressure to 1.8 bar at pressure reducer.
 Finish test (machine is turned off).
 Dismantle setting equipment and remove auxiliary
nipple.
 Replace filler cap.
Setting pressure reducer with KonfigTool
 Adjust test environment
 set pressure reducer  start
 Remove filler screw-cap
 Screw auxiliary nipple to accept plug-in connector into
the water tank filler.
 Mount auxiliary tool on filler.
 Start test on laptop
Supply valve opens
 Read pressure on pressure gauge.
 Set pressure to 1.8 bar at pressure reducer.
 Finish test
 Dismantle setting equipment and remove auxiliary
nipple.
 Replace filler cap.
