General Information
11
EN
1 General Information
1.1 Intended Use
The Supplementary Light is used for the illumina-
tion of a dark, dusty or sooted environment during
the inspection with the cam
era system Wöhler VIS.
The Wöhler Supplementary Light 26/40 is used
with the detachable camera head Ø 26 and
40mm.
It has to be installed between the camera
head and rod. It will be switched on and off with the
keys of the camera system.
1.2 Direction
Wöhler Technik GmbH
Wöhler-Platz 1
33181 Bad Wünnenberg
Tel.: +49 2953 73-100
Fax: +49 2953 73-250
E-Mail: info@woehler.de
1.3 Important Note
ATTENTION!
The Supplementary Light is only waterproof (IP
67) when the camera head and the rod are con-
nected. Never cle
an the Supplementary Light with
water, when the camera head and rod are not
connected.
2 Technical Data
Description
Data
Light
18 white LEDs
Outer diameter
53 mm Ø
Connection Camera
Head
Clutch soket with 8
poles
Connections
M 30 x 1,5 internal
thread
Waterproof (only with
camera head and rod)
IP 67
Power Supply
Via video inspection
system
