Wolck 1GE+1FE+WiFi+CATV - Application Chart; Technical Parameters

1.2 Application Chart
Figure 2 Application Chart
1.3 Technical Parameters
Technical item
1GE+1FE+WiFi+CATV
Interface
1 WDM, SC/APC connector or 1 PON SC/UPC+CATV SC/APC
connector, single/double fiber.
GPON: uplink 1.25Gbps, downlink 2.5Gbps; EPON: symmetric
1.25Gbps.
Wavelength
PON Tx1310nm,Rx 1490nm, CATV 1550nm.
LAN interface
1x 10/100/1000Mbps Auto-negotiation Ethernet interfaces.
1x10/100Mbps Auto-negotiation Ethernet interfaces.
Wireless
Compliant with IEEE802.11b/g/n, 300Mbps, 2T2R, 2 external antenna.
CATV
SCTE type F
LED
7, For Status of POWER、LOS、PON、LAN、WiFi、CATV.
Operating
condition
Temperature: -5℃～55℃
Humidity: 10%～90%（non-condensing）
Storing
condition
Temperature :-30℃～60℃
Humidity :10%～90%（non-condensing）
Power supply
DC 12V/1A
Power
consumption
≤7W
Dimension
185mm×120mm×34mm（L×W×H）
Net weight
0.3Kg
Table 1 Technical Parameters
