C HIMNEY W ALL AND C HIMNEY I SLAND H OODS
30"
(76.2)
18"
(45.7)
21"
(53.5)
12"
(30.5)
6
7
/8"
(17.5)
4"
(10.2)
E
2"
(5.1)
6"
(15.2)
30
1
/2" min
(77.5)
to
48
1
/2" max
(123.2)
42"
(106.7)
27"
(68.6)
9
1
/4"
(23.5)
18"
(45.7)
12"
(30.5)
33
9
/16" min
(85.1)
to
47
1
/16" max
(119.7)
DIMENSIONS
IMPORTANT NOTE: The chimney
wall and chimney island hoods are
recommended for use over the Wolf
gas and electric cooktop instruments.
They are NOT recommended for the
Wolf ranges and rangetops.
Chimney wall and chimney island
hoods are available in the following
sizes:
Chimney Wall Hoods – 30 and 36-
inches wide (21-inches deep)
Chimney Island Hood – 42-inches
wide (27-inches deep)
21"
(53.3)
9
1
/4"
(23.5)
35
7
/16"
(90.0)
32
11
/16" min
(82.9)
to
50
7
/8" max
(129.2)
18"
(45.7)
4"
(10.2)
12"
(30.5)
E
2"
(5.1)
6"
(15.2)
30-inch Chimney Wall Hood
Overall Dimensions
36-inch Chimney Wall Hood
Overall Dimensions
42-inch Chimney Island Hood
Overall Dimensions
FEATURES
• Front Mounted Controls
• LED Indicators
• Three-Speed Blowers
• Filter Clean Timer
• Delay Feature
• Sealed Three Level Halogen
Lighting
• Stainless Steel Filter Cover with
Aluminum Mesh
• Heat Sentry
• Seamless Construction
• Built-In Back Draft Damper
• Internal/Remote Blowers
• Fits 8 to 9-foot ceilings
