Wolf AHU TE - Function Symbols

4
3064058_201610
AHU TE
AHUW TE
Functionsymbols
Functionsymbols
+
+
+
°C
-
_
Fan section Fan section
Bagltersection Heater section
KGXD section KGX section
Empty section Empty section with
damper
Empty section with
damper and tray
Empty section with
tray
Silencer section Humidiersection
Heater section with
frost protection frame
Cooling section
Rotary heat ex-
changer section
GS-PWT section
