Anti-Tip Bracket
INSTALL BRACKET
Drywall application | After properly positioning the anti-tip
bracket, mark holes, then use a Philips screwdriver or a low
rpm power drill to drive the wall anchor into the surface of
the wallboard until ush. Pre-drill holes if needed. For hard
wallboard or double-board construction, use a
1
/4" drill bit.
For solid plaster, use a
7
/16" drill bit. Refer to the illustration
below. Use #8 screws and at washers to fasten the bracket
to the wall.
Wood oor application | After properly positioning the
anti-tip bracket, drill
3
/16" (5) pilot holes through the oor.
Use #12 screws and at washers to secure the bracket to
the oor.
Concrete oor application | After properly positioning
the anti-tip bracket drill
3
/8" (10) holes into the concrete a
minimum of 1
1
/2" (38) deep. Use
3
/8" wedge anchors to
secure the bracket to the oor.
ANTI-TIP BOLT ADJUSTMENT
Once the bracket is secure, adjust the anti-tip bolt so the
top of the washer is
7
/8" (22) maximum from the oor. Slide
the range into the opening and verify the anti-tip bolt is
engaged. Refer to the illustrations below.
ANTI-TIP
BRACKET
WALL
ANCHOR
Wall anchor installation.
INSTALLATION
7
/8" (22) MAX
ANTI-TIP
BOLT
ANTI-TIP
DEVICE
ENGAGED
Anti-tip bolt adjustment. Anti-tip bolt engaged.
