49
5
/8"
(1260)
OPENING
HEIGHT
50
15
/16"
(1294) min
FLUSH INSET
HEIGHT
28
1
/2" (724)
OPENING WIDTH
30
3
/8" (772) min
FLUSH INSET WIDTH
7
/8"(22) TOP CLEAT
7
/16" (11)
BOTTOM CLEAT
SIDE CLEATS
24
3
/4"*
(629) min
FLUSH INSET
DEPTH
1" (25)*
*For black glass model, increase dimension by
1
/4" (6).
NOTES: Minimum base support 400 lbs
(181 kg).
Location of electrical supply within opening may require additional cabinet depth.
Cleats may be visible and should be finished to match cabinetry.
Dashed line represents profile of unit.
FRONT VIEWSIDE VIEW
TOP VIEW
1" (25)
SIDE CLEATS
5"
(127)
4"
(102)
E
E
E
67" (1702)
TYPICAL
30" (762) E Series Double Oven
FLUSH INSET INSTALLATION
Wolf Built-In Ovens 12
