Schleifmaschine MAMBO, Artikel-Nr. 013495
, ab 324 vom 21-09-04Fugenfräse FRÄSMASTER
Speed control
Adjust the speed of the discs with switch (4). Turning clock-wise
increases the speed, turning anti-clock-wise decreases the
speed. The optimal speed is dependent on the disc used and the
subfloor.
The table below It is meant as guiding principle for the user.
Always test the optimum speed in each case. Always start at
low speed and then increase the speed.
Speed Use Recommended disc
160-200 Grinding screed and Grinding paper, grinding
levelling compounds gauze
200-300 grinding parquet Grinding gauze
removing levelling compounds Carbide grinding disc and
and adhesive residues System- milling disc
300-400 Polishing resilient flooring Pads
Removing the sealing of Scrubbing brush
resilient floors
removing levelling compounds System- milling disc
400-450 Hard grinding and milling works System-milling disc
Multi-Speed polishing of Pads
resilient floors
Always remove discs or brushes after work.
Remove also the cleaning tank, if one has been used. Always
disconnect the power cord after work or when leaving the machine.
Transportation
For transportation fold the handle forwards. For carrying the
machine, use the recessed grips at the front and at the back.
6.0 Accessories for the grinding machine
6.1 Vacuum unit
The vacuum unit Micropac or an external industrial vacuum
cleaner may be used.
Mounting the vac Micropac (Item-No. 013496)
Assemble the vacuum unit from the front of the handle of the
machine.
insert vac into the lower support
turn vac at the top against the handle and fasten the thumb
screws
fasten hose to the vac by turning clockwise
attach hose to the outlet spigot of the machine
The speed for finish grinding on levelling compounds
should not be higher than 200 r.p.m. Otherwise the
adherence of adhesives may be severely reduced.
(4)
