9
Setting Up the Wood Chipper
Step 5: Read assembly instructions
and prepare tools.
Setting Up the Wood Chipper (continued)
Step 6: (Left) Raise and block the
front of the chipper base with a 4x4
as shown. Attach the trailer tongue
support frame (16mm wrench, 17mm
wrench) Note: be sure that the frame
is orientated as shown in the picture.
It will not work if attached upside
down. The metal plate must be on top.
(See arrow)
Step 7: Install the tongue as shown
using two M10x65mm bolts.
Step 8: Attach the support leg using a
M10x85mm bolt as shown.
