18
Operating the Wood Chipper
Stopping the Engine
To stop the engine in an emergency,
simply turn the engine switch to the
OFF position. Under normal conditions,
use the following procedure.
1. Move the throttle lever to the
MIN position. [See Fig. 6]
2. Turn the engine switch to the
OFF position. [See Fig. 4]
3. Turn the fuel valve lever to the
OFF postion. [See Fig. 7]
FIG 6
FIG 7
Setting Engine Speed
Position the throttle lever to the
engine MAX speed. [See Fig. 8]
FIG 8
Wood Chipping
Wood and branches should be no larger than 2.5" inches in
diameter.
Do not place your hands into the chute when loading. This is a
very UNSAFE method and could result in injury to your hands.
Do not reach or step across the rail while the Wood Chipper
is running. This is a very UNSAFE method which could cause
personal injury, even death.
