English Metric
Description Illustration BH85 BH100 BH85 BH100
Tractor PTO HP 30 - 100 HP 40 - 100 HP 22 - 75 kw 30 - 75 kw
Digging Depth - Maximum F 103 in. 121 in. 2616 mm 3073 mm
Digging Depth - 2’ Flat G 102 in. 120 in. 2591 mm 3048 mm
Digging Depth - 8’ Flat H 82 in. 102 in. 2083 mm 2591 mm
Reach from Swing Pivot M 141 in. 161 in. 3581 mm 4089 mm
Loading Height K 83 in. 100 in. 2108 mm 2540 mm
Loading Reach L 61 in. 70 in. 1549 mm 1778 mm
Transport Height A 94 in. 104 in. 2388 mm 2642 mm
Transport Length B 55 in. 55 in. 1397 mm 1397 mm
Swing Arc 180° 180° 180° 180°
Bucket Rotation 180° 180° 180° 180°
Stabilizer Spread - Up 76 in. 76 in. 1930 mm 1930 mm
Stabilizer Spread - Down 102 in. 102 in. 2591 mm 2591 mm
Leveling Angle* 10° 10° 10° 10°
Relief Pressure 2465 psi 2465 psi 17 Mpa 17 Mpa
Bucket Digging Force 4600 lbs 4600 lbs 20462 N 20462 N
Dipperstick Digging Force 2940 lbs 2720 lbs 13078 N 12099 N
Bucket Capacity (Heaped) cu.-ft. cu.-meter
12" (305 mm) 1.37 0.039
15" (381 mm) 1.84 0.052
18" (457 mm) 2.32 0.066
24" (610 mm) 3.27 0.093
36" (914 mm) 3.17 0.090
Per Definitions in Standards - SAE J49 and SAE J1234
* Depends on Tractor Model and Tire Sizes
