Woods FZ23B - Page 39

Parts 39
MAN0875 (2/8/2011)
PTO CLUTCH & PUMP ASSEMBLY PARTS LIST
REF PART QTY DESCRIPTION
1 73746 1 Splined power shaft (FZ28K) -or-
1 73825 1 Splined power shaft (FZ23B)
2 75358 1 PTO sheave
4 3886 * 1 Key 1/4 x 1-1/4
5 78044 2 1" Pillow block bearing w/set screw
6920*6
3/8 NC x 1-3/4 HHCS - GR5
7565*
15
3/8 Flat washer
8838*
11
3/8 Lock washer
9835*
10
3/8 NC Hex nut
10 -------- *
4
1/4 NF Socket head set screw
11 58567 * 2
90 ° Grease fitting
12 73425 1 Bearing guard
13 2457 * 10
1/4 NC x 3/4 HHCS - GR5
14 5336 *
4
1/4 Flat washer
15 70065 * 4 1/4 Whiz nut
16 73758 1 Cable, clutch stop
17 75507 1 Drive idler arm (includes item 42)
18A 75403 2
Pump sheave (Parker
®
)
18B 78751 2
Pump sheave (Hydro-Gear
®
)
19 74075 1 Electric clutch, mag-stop 1-1/8
20 70355 1 Retaining washer
(FZ28K)
21 62533 1 7/16 NF x 2 HHCS GR5 (FZ23B) -or-
21 71826 1 7/16 NF x 1-1/2 HHCS GR5
(FZ28K)
22 78095 1 PTO V-belt set, matched
23 12169 * 6 3/8 NC x 1-1/4 HHCS - GR5
REF PART QTY DESCRIPTION
24 6698 * 6 3/8 NC Center lock nut
25 31138 * 2
3/8 NC x 3-1/2 HHCS - GR5
26 73416 2 Idler sleeve
27 75362 1 PTO Idler Arm (includes item 42)
31 75476 1 3-1/4 x 5/8 x 1-5/8 Idler
32 73826 2 Extension spring
33 73715 1 Spring Lug (F21D/F25L)(73743,
73745)
34A 75402 1
Drive V-belt (Parker
®
)
34B 78755 1
Drive V-belt (Hydro-Gear
®
)
35A 75543 1
Pump, Left (Parker
®
)
35B 78753 1
Pump, Left (Hydro-Gear
®
)
36A 75538 2
Fan (Parker
®
)
36B 78774 2
Fan (Hydro-Gear
®
)
37 73964 2 Key, 5 mm x 25 mm
41 71156 1 3/8 NC x 6 hook bolt
42 74068 2 Bushing idler arm
43 73745 1 Spring lug (FZ28K)
44 73743 1 Spring lug (FZ23B)
45 74074 1 D-Drive (FZ23B)
46 75194 2 Bushing 17 mm
47 75363 2 Collar set 1" ID
48 75360 1 Idler
49 34440 1 Bushing 1"
50 5664 1 7/16 Lock washer
51 75537 AR Seal kit
52A 75542 1
Pump, right (Parker
®
)
52B 78752 1
Pump, right (Hydro-Gear
®
)
* Standard hardware, obtain locally
AR As required
(Rev. 6/18/2013)
