27
- Insert the clamping device with a new or sharpened knife and align laterally with the cut-
ter head.
- Put the blade set block on the top surface of the fixed table as shown in figure 9. Make
sure that the face (A) of the blade set block is located on the top surface of the fixed ta-
ble, the face (B) to the end face of the fixed table and the face (C) on the edge of the
knife.
- Press the blade set block with one hand and tighten the tensioning screws (21) by turning
counter clockwise with the open-ended spanner provided.
- Finally push the knife guard (9) back in position to cover the knife.
TROUBLESHOOTING
Problem Cause Solution
Machine cannot
be switched on.
- No main voltage
- Carbon brushes worn
- Check power supply.
- Take the machine to an authorized
service center.
Machine switches
itself off when
idling.
-
Mains failure - Check mains back-up fuse and
change it if needed.
Machine stops
while planing is in
progress.
-
Blunt knives or excessive feed
rate.
- Replace or sharpen knives or re-
duce feed rate.
Speed drops while
planing is in pro-
gress.
- Cutting depth too great
- Feed rate too fast
- Blunt knives
- Reduce cutting depth.
- Reduce feed rate.
- Sharpen or replace knives.
Unsatisfactory
finish.
- Blunt knives
- Uneven feed
- Not connected to dust extrac-
tor unit (not supplied)
- Sharpen or replace knives.
- Plane with constant pressure and
reduce feed rate.
- Connect to it.
Chip ejection
blocked while
planing is in pro-
gress.
- No dust extractor unit
- Wood too damp
- We recommend to use a dust ex-
tractor unit while using the ma-
chine.
Uneven feeding
rate while rotary
planing is in pro-
gress.
- Rubber belt too loose
- Dust
- Check the rubber belt and change
if necessary.
- Clean the dust from the two
springs located on the side cover.
Electrical and electronic equipment must not be disposed of with household waste. Instead, hand
it over to a designated collection point for recycling. Contact your local authorities or retailer for
further information.
