Manual 26059 EGCP-1 Engine Generator Control Package
Woodward 17
Discrete I/O
1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6
I I I I
O O -----
Volt Bias: 0
Speed Bias: 0
Figure 4-11. I/O Status
DI:
Discrete Inputs 1 through 16.
DO:
Discrete Outputs 1 through 11.
Volt Bias:
% voltage bias output (±100% range).
Speed Bias:
% speed bias output (±100% range).
Discrete Inputs
1. Automatic Switch
2. Test Switch
3. Run with Load Switch
4. Volts Raise
5. Volts Lower
6. Speed Raise
7. Speed Lower
8. Gen Circuit Breaker Aux Contact
9. Mains Circuit Breaker Aux Contact
10. Process Switch
11-16. Remote Alarm/Shutdown Inputs
Discrete Outputs
1. Mains Breaker Close/Contactor Close
2. Gen Breaker/Contactor Close
3. Engine Preglow
4. Fuel Solenoid
5. Engine Crank
6. Visual Alarm Relay
7. Local Bus PT Connect
8. Mains PT Disconnect
9. Mains Breaker Trip
10. Gen Breaker Trip
11. Audible Alarm

Woodward EGCP-1 Specifications

General

Display	LCD
Output Voltage	120/240V AC
Protection Features	Overvoltage, Undervoltage, Overfrequency, Underfrequency, Overcurrent
Output Frequency	50/60 Hz
Control Type	Digital
